Alberta House

The design received acclaim from the Mayor’s office and makes a significant contribution to the provision of affordable housing in Tower Hamlets and Docklands with some 50% of dwellings being classed "affordable".

Alberta House, Tower Hamlets

The design maximises the potential of a very difficult site. Developed by the Swan Housing Association, the scheme stands to the immediate west of Ballymore's New Providence Wharf and Ontario Tower only a short walk from the Blackwall DLR station.

The development includes a number of features such as a biomass boiler, the latest in insulation to avoid heat-loss, and a green roof that's intended partly as an aerial nature reserve.

The LTS manifold is used but is ﬁtted with a thermometer and pressure gauge. Zone control includes a preset TS-valve per ﬂoor heating loop with provision for control using a thermal actuator and also for manual operation (24V or 230V thermal actuators and hand caps can be ordered separately).

Dimension	Height	Width	Depth
2	220	400	160
3	220	400	160
4	220	400	160
5	220	460	160
6	220	520	160
7	220	580	160
8	220	640	160
9	220	700	160
10	220	760	160
11	220	820	160
12	220	880	160
13	220	940	160
14	220	1000	160
15	220	1060	160
16	220	1120	160
17	220	1180	160
18	220	1240	160
19	220	1300	160
20	220	1360	160
